Sanitary fan J11v
Generally
The sanitary fan for our popular J11v flat roof tile is used for rainproof roof ducting for ventilating sanitary areas. It is made of unbreakable, durable die-cast aluminium and has the same rebate system as the J11v flat tile. The sanitary vent is supplied with a DN 125 flexible hose, cap and sealing sleeve.
- Zubehör
- Non-ceramic accessories
- Number of available colors
- 17 Farben
Maße
| Overall dimension | 44,5 x 30,4 cm |
|---|---|
| Overall dimension CA | 44 x 29,1 cm |
| Cover length | 33,3 - 36,5 cm |
| Cover length CA | 32,8 - 36 cm |
| Cover width | 24,6 cm |
| Cover width CA | 23,6 cm |
| Diffuser size | 12,5 |
